Tungsten Carbide
Description
Tungsten carbide is a black hexagonal crystal with metallic luster, and its hardness is similar to diamond. It is a good conductor of electricity and heat. It has been widely used in manufacturing high-speed cutting tools, kiln structure materials, jet engine components, cermets and resistance heating elements, etc.Pure tungsten carbide is brittle and can reduce brittleness if a small amount of metals such as titanium and cobalt are added.As a super hard tool material and wear resistant material, it can form a solid solution with many carbides.WC-TiC -Co cemented carbide tools have been widely used.It can also be used as a modified additive for NbC-C and TaC-C ternary system carbides, which can not only reduce sintering temperature, but also maintain excellent performance and can be used as a space material.
Application
Hard alloy, resistance heating element, cermet etc
Physical Characteristics
CAS:12070-12-1 Molecular weight: 195.85 Crystal Structure: hexagonal crystal Boiling Poit:6000℃ | Molecular formula: WC Color: gray Melting Point: 2870°C Density: 15.63g/cm3 |
Chemical Characteristics
Grade | FWC-1 | FWC-2 | FWC-3 | FWC-4 |
Main contents（%） | WC | >99.8 | >99.8 | >99.8 | >99.8 |
Ctotal | 5.9-6.2 | 5.9-6.2 | 5.9-6.2 | 5.9-6.2 |
Cfree | 0.20 | 0.06 | 0.06 | 0.06 |
Impurity contents （%）Max | Ca | 0.002 | 0.002 | 0.002 | 0.002 |
Fe | 0.02 | 0.02 | 0.02 | 0.02 |
S | 0.002 | 0.002 | 0.002 | 0.002 |
O | 0.20 | 0.15 | 0.10 | 0.08 |
Si | 0.003 | 0.003 | 0.003 | 0.003 |
K | 0.0015 | 0.0015 | 0.0015 | 0.0015 |
Al | 0.002 | 0.002 | 0.002 | 0.002 |
Mg | 0.002 | 0.002 | 0.002 | 0.002 |
Na | 0.0015 | 0.0015 | 0.0015 | 0.0015 |
Mo | 0.01 | 0.01 | 0.01 | 0.01 |
F.S.S.S | ＜0.6 μm | 1.0-2.0 μm | 2.0-4.0μm | 4.0-30μm |
The special requirement of size and chemical can be produced |
Why Choose Us:
1. You can get the perfect material according to your requirement at the least possible price.
2. We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
4. e guarantee to give a response within 24hours(usually in the same hour)
5. You can get stock alternatives, mill deliveries with minimizing manufacturing time.
6. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.
Quality Assurance(including both Destructive and Non-Destructive)
1. Visual Dimension Test
2. Mechanical examining like tensile, Elongation and reduction of area.
3. Impact analysis
4. Chemical examination analysis
5. Hardness test
6. Pitting protection test
7. Penetrant Test
8. Intergranular Corrosion Testing
9. Roughness Testing
10. Metallography Experimental Test
